Eurobox volumetric calculator
Enter how many boxes of each size you have and it returns the figures a forwarder is going to ask for anyway: total volume, how many Euro pallets that becomes at a stack height you choose, and how much of a 20 ft container it fills — by volume and by pallet floor positions, which are rarely the same constraint.
It exists because we kept doing the arithmetic by hand after breaking down pallets, getting it slightly wrong, and paying for the difference in volumetric weight.
The boxes the numbers describe
EU4315
EU6423
EU6434
Drag to turn one over. These are the three
sizes we actually stock, modelled to their external dimensions — the
volumes above are external too, which is what the calculator works in. Each
box is framed to fill its own card, so read the figures rather than the
pictures for relative size. The code on the side is our own label
convention: EU then the long side, the short side and the
height, all in whole centimetres.
| What it returns | Volume in m³ and litres, Euro pallet loads with per-layer layout diagrams, and 20 ft container utilisation by volume and by floor position. |
|---|---|
| Box sizes | 600 × 400 (heights 12–42 cm, including 17.5, 23 and 31 cm), 400 × 300, 300 × 200, 800 × 600 — plus custom dimensions. |
| Pallets | EUR-1 (1200 × 800 × 144 mm) or EUR-6 half pallet, at a selectable maximum stack height. |
| Output | On-screen, plus an A4 PDF report via the browser's print dialogue. |
| Runs | Entirely in your browser. Nothing is uploaded, stored or logged — there is no server behind it to send anything to. |
| Cost | Free. No account, no email address, no trial. |
What it assumes
- External box dimensions, stacked in aligned grid layers with no overhang.
- Single-SKU pallets — box types are not mixed on one pallet.
- 11 EUR-1 pallets per 20 ft container floor; 33.2 m³ internal volume.
Counts are conservative planning estimates, not a packing optimisation. A good loader will beat them. Quote from a forwarder's own measurement, not from this, when money turns on the number.
Built and published by Daniel Rosehill; hosted here as a client resource. Use it for whatever you like.
Our receiving points, in your system
Every dropoff point is published as a downloadable record so a carrier can add us without retyping anything — and so the coordinates in the vCard cannot disagree with the coordinates on the page.
Written up rather than explained twice
LCL pallet receiving
The chain from consolidation to break-down, the pre-advice we need, what a kerbside unload requires, and the exceptions that come up most.
Read it →
Why name a lane
How we reference a five-week movement so that a pre-advice raised in Jerusalem and a POD signed in Connecticut reconcile against each other.
Read it →Herman, as a 3D model
The company mascot is a real knitted donkey, scanned and cleaned up as a glTF binary. He is on this site because he is ours, and he is downloadable because a small, clean, oddly specific .glb is a genuinely useful thing to have when you are testing a 3D viewer.
810 kB, single mesh, no animation clips.
